The Meade 14" f/8 LX850 ACF Telescope is a flagship model in Meade's equatorial (EQ) mounted telescope series, renowned for its exceptional performance and versatility in both visual observation and astrophotography. This telescope is built around the robust LX850 mount, designed to support heavy payloads and facilitate high-precision imaging.

Specifications:

  • Aperture: 14 inches
  • Focal Length: 2845mm
  • Focal Ratio: f/8
  • Optics: Advanced Coma-Free (ACF) with Ultra-High Transmission Coatings (UHTC)
  • Mount Type: German Equatorial Mount (GEM)
  • Weight:
  • Optical Tube Assembly: 63 lbs
  • LX850 Head Assembly: 60 lbs
  • Tripod: 50 lbs
  • Total Assembled Weight: 251 lbs
  • Included Counterweights: 26 lbs (x3)

Key Features

Advanced Coma-Free Optics:

  • Provides flat fields of view with no coma or diffraction spikes, even at the edges of wide-angle eyepieces and cameras.
  • UHTC coatings enhance image brightness and contrast, revealing fine details in deep-sky objects and planets.

Robust Mount and Versatile Design:

  • Supports up to 90 lbs, allowing for various telescope tubes to be mounted using Losmandy and Vixen-style dovetail rails.
  • Ideal for small to medium observatories and portable setups.

StarLock Automatic Guider:

  • Integrated guiding system automates target acquisition and tracking during exposures.
  • Features wide-field and narrow-field CMOS sensors for precise autoguiding.

Crayford-Style Zero Shift Focus Mechanism:

  • Eliminates focus shift and backlash for smooth focusing.
  • Includes a two-speed focus knob for coarse and fine adjustments.

Mechanical Advantages:

  • Modular design allows for easy breakdown and transport.
  • Includes a sliding counterweight system for optimal balance and tracking performance.

Advanced Electronics and AutoStar II System:

  • Equipped with AutoStar II hand controller with a 145,000-object library and multiple guided tours.
  • Features Permanent Periodic Error Correction (PPEC) and precise star alignment with GPS.

Additional Features

Enhanced Imaging Capability:

  • Optional 0.68x Focal Reducer transforms the telescope into a faster system for deep space imaging, reducing exposure times and expanding the field of view.
  • Supports both astrophotography and visual observation with high-resolution detail.

Power and Connectivity:

  • Powered by an external 12v DC source; includes a Meade 12v 5 amp Universal Power supply.
  • Multiple input/output ports for connectivity, including RS-232 PC interface and Autoguider port.

Quality Manufacturing:

  • Designed and manufactured in North America with high-quality materials and precision engineering.

The Meade 14" f/8 LX850 ACF Telescope is a versatile and powerful instrument, ideal for both amateur and professional astronomers. Its advanced optics, robust mount, and comprehensive features make it an excellent choice for exploring the night sky, whether for visual enjoyment or capturing stunning astrophotographs.



Annotation 2024-08-07 184506.png

Annotation 2024-08-07 184530.png
